尔云A10s规格如下表所示： CPU ARM Cortex-A8 32KB I-Cache
32KB D-Cache
256KB L2 Cache GPU ARM Mali-400 Video HD Video decoding up to 1920×1080@30fps
Support various video decoding formats, including H.264/H.263, VC1, MPEG 4/2/1, Xvid, VP6/VP8, AVS etc.
H.264 HP video encoding up to 1920×1080@30fps Audio Codec Integrated audio codec
MIC/FM/LINEIN input HDMI HDMI 1.4
1080P output Memory 16/32-bit DDR2/DDR3
- Memory capacity up to 1G Bytes
MLC/TLC/SLC/EF-NAND
- 64-bit ECC
- Support NAND of 4xnm, 3xnm, 2xnm, etc
- Support NAND of Samsung, Toshiba, Hynix, etc Display Multi-channel HD display Integrated HDMI 1.4
YPbPr, CVBS, VGA
Multiple LCD interfaces, including CPU, RGB, LVDS up to Full HD Boot Device NAND Flash SPI NOR Flash
SD Card
USB Connectivity USB2.0 OTG USB2.0 HOST（OHCI/EHCI）
SD Card V3.0, eMMC V4.2
SPI, TWI and UART
TS Port
EMAC
CSI
IIS Package BGA33614mm ×14mm OS Android 4.0.4 or up Application HDMI Dongle Android Box
